Name: | Security Hard Tag | Place Of Origin: | Guangzhou, China (Mainland) |
---|---|---|---|
Label Thickness (excluding Liner): | Maximum 1.9mm | Label Thickness(including Liner): | Maximum 2.0mm |
Usage: | Clothing EAS System | Certification: | ISO9001 |
High Light: | anti theft tags,retail security tags |
HD2034 (58K) EAS am Anti theft Shoplifting hard tag Security for Clothing in EAS System made in china
Dr Barcode Label, EAS AM Label, Barcode Label, Retail Security Systems, 58KHz AM DR Soft Label,
Detailed Product Description
Electrical Specifications
Frequency : 58kHz
Deactivation : 100%
Operating Distance: Up to 2m (8ft) in Dual Pedestal System.
Product Details:
Frequency | 58kHz |
label length | 45mm ± 0.2mm |
label width | 10.8mm ± 0.2mm |
label thickness (excluding liner) | Maximum1.9mm |
label thickness(including liner) | Maximum 2.0mm |
Materials of Construction
plastic housing : Polystyrene/polyethylene 0.35mm thickness.
resonator(s) : Amorphous alloy material.
Laminate : Low Density Polyethylene / Polyester /Polyethylene 0.12mm
Bias : Semi-hard magnetic material
Laminate : Low Density Polyethylene/Polyester 0.08mm
Adhesive : Double-coated acrylic-based adhesive
Minimum peel strength:≥15 N/25mm
release liner : Double-sided, silicon-coated Kraft liner 0.12mm thick
Environmental Constraints
Shelf Life: Two year from date of manufacture when Labels are stored between15-32 (60°F -90°F) and 30-80%RH.
Temperature: Maximum storage temperature not to exceed 50 (122°F) for 96hours at 80% RH.
Humidity: Unaffected by 80% humidity at 50(122°F), up to 96 hours
We made products with good quality by doing these things:
- sourcing the best raw materials
- strictly control the production processes
- constantly monitor the product quality
- adopting innovative supply chain management system
