Removable Lanyard Wire Cable for EAS Tag

Basic Information
Place of Origin: Guangzhou, China (Mainland)
Brand Name: QIDA
Certification: ISO9001
Minimum Order Quantity: 5000 Piece/Pieces
Price: Get Latest Price
Packaging Details: Carton
Delivery Time: 30 Days
Payment Terms: T/T
Detail Information
Highlight:

amorphous alloy core

,

amorphous metal alloys


Product Description

Removable Lanyard Wire Cable for EAS Tag



QQ20160817163052





Dr Barcode Label, EAS AM Label, Barcode Label, Retail Security Systems, 58KHz AM DR Soft Label,




Detailed Product Description



Sourcing tag



The AM Label provides adequate detection and very high deactivation performance.

Low-price AM labels are available in a wide range of standard and custom styles and are available in sheets and rolls to accommodate retailers with source-tagging and other in-store product protection requirements.

Retailer Values



1. AM technology and manufacturing process to provide the highest in detection performance



2. Non-reactivatable format helps prevent inadvertent reactivation,reducing nuisance EAS alarms at the store entrance



3. Merchandise arrives sales-floor ready, enabling immediate product availability.


Product Details:



Frequency 58kHz
label length 45mm ± 0.2mm
label width 10.8mm ± 0.2mm
label thickness (excluding liner) Maximum1.9mm
label thickness(including liner) Maximum 2.0mm





-10.jpg-11.jpg-12.jpg-13.jpg-14.jpg-15.jpg-16.jpg-17.jpg-18.jpg111122222






Electrical Specifications



Frequency : 58kHz



Deactivation : 100%



Operating Distance: Up to 2m (8ft) in Dual Pedestal System.






Materials of Construction



1 . Plastic housing



2 . Resonator



3 . Laminate



4 . Bias



5 . Adhesive



6 . Release Liner



plastic housing : Polystyrene/polyethylene 0.35mm thickness.



resonator(s) : Amorphous alloy material.



Laminate : Low Density Polyethylene / Polyester /Polyethylene 0.12mm



Bias : Semi-hard magnetic material



Laminate : Low Density Polyethylene/Polyester 0.08mm



Adhesive : Double-coated acrylic-based adhesive



Minimum peel strength:≥15 N/25mm



release liner : Double-sided, silicon-coated Kraft liner 0.12mm thick






Environmental Constraints



Shelf Life: Two year from date of manufacture when Labels are stored between15-32 (60°F -90°F) and 30-80%RH.



Temperature: Maximum storage temperature not to exceed 50 (122°F) for 96hours at 80% RH.

Humidity: Unaffected by 80% humidity at 50(122°F), up to 96 hours

Usage Instructions



Place in least conspicuous location.



Do not cover warnings, expiration dates or important consumer information.



It is recommended that the surface to which the label is applied be clear and free of all dirt, grease, oil, etc.



Ambient magnetic field of labeled product greater than 100mG may result in reduced label performance.



Label not to exceed temporary magnetic field exposure greater than 8 Gauss.



Why Choose us?



1. One-stop security solution Supplier, can be help you to save time and costs.



2. Our own manufacturer could strictly control the quality, and make the cost to be the most competitive one.



3. Easy opration, attractive design.



4. Professional technique supports and great service.



5. Fast delivery and safe shipping way.



6. Providing excellent protection for your merchandize.



Shipping Method:



1) Fast delivery: By Express courier, such as DHL, TNT, FedEx, UPS and EMS



2) Cheap way: By air or by sea shipment.




Quality Warranty:



1 - 2 years warranty from the date of delivery, a lifetime technical support.
